Model: CH-70
Details:
＃ Use: CH-70 split hydraulic punching machine R & D in recent years for copper, aluminum row, angle iron, iron and other metal materials punching hydraulic punching tools. In the following figure, five CH-70 punching machines lined up in a large flow hydraulic pump driven lath iron, angle iron punching five holes in 10 seconds like to put a chain gun, like turn red finished. Speed of fast, high efficiency, won the favorite.
＃ Features: 1. Punching speed is fast, accurate positioning. No noise, no chips, safe and clean operation. 2. Easy to carry, suitable for field operations or fixed at the factory for mass production. (3) single-hole back to the oil. Mold using Cr steel quenched after heat treatment, stamping resistance, long life. 4 punching die can be made of various shapes.
＃ Accessories: random distribution of the mold Φ10.5 Φ13.8 Φ17.5, Φ20.5 four pay each one of Unloading fork and hex wrench. The rest of the mold:
Φ5.5, Φ6, Φ6.5, Φ7, Φ7.5, Φ8, Φ9 need to be customized.
＃ output: 35T
Maximum Punching thickness: copper, aluminum: 12mm; iron: 10mm
＃ throat depth: 110mm
＃ Weight: 28kg
＃ with the pump: hydraulic electric pump
＃ Packing: wooden box |
